Cat5e Plenum 350MHz Solid Bare Copper 24AWG 1000ft Network Cable
This Cat5e cable uses 24AWG solid bare copper conductors in a 4-pair UTP configuration. It supports up to 1Gbps speeds with 350MHz bandwidth. The plenum-rated jacket is suitable for air-handling spaces. Packaged in an easy-pull box for organized installation. Twisted pairs help reduce crosstalk and electromagnetic interference, supporting consistent signal transmission in structured cabling installations.
Out of stock
- SKU
- NYC-51x
| Feature | Details |
|---|---|
| Cable Category | Cat5e |
| Category Type | Ethernet Cables |
| Speed | 1 Gbps |
| Frequency | 350 MHz |
| Conductor Diameter | 24 AWG |
| Jacket Rating | CMP (Plenum) |
| Cable Length | 1000 feet |
| Conductor Material | 100% Pure Copper |
| Special Features | High-Speed, Noise Reduction, Low Latency, Easy Installation |
| For Use | Indoor Installations |
| Connector Type | RJ45 |
| Packaging | EZ Pull Box |
| Cable Diameter | 5.5 ±0.3mm |
| Certifications | FCC, CE, CSA, ISO/IES, RoHS |
| PoE Compatibility | N/A |
| Twisted Pair Colors | Pair 1: Blue, White-Blue Pair 2: Orange, White-Orange Pair 3: Green, White-Green Pair 4: Brown, White-Brown |
Buy Cat5e Plenum Cable 1000ft
CAT5E PURE COPPER CABLE
- Solid Copper Cat5e Cable
- 1 GBit/s, 350 MHz
- 24 AWG, 4 Pairs, Unshielded
- Plenum Jacket
- Competitive Price, Easy to Install
PLENUM NETWORK CABLE
- Indoor-rated cable jacket
- Ideal for air-handling spaces
- Fire-resistant white Cat5e Cable
- Low non-toxic smoke emitting
- Easy to handle
24 AWG SOLID COPPER
- 24 AWG thick wires
- 8 total wires, 4 pairs
- Solid bare copper
- Ductile and easy to pull
- Excellent signal integrity
LONG-LASTING COPPER CABLE
- The cat5e pure copper cable is reliable & long-lasting
- Bare copper conductors ensure high performance
- Highly resistant to harsh environments
- Use it for commercial and residential LAN
MINIMAL LATENCY
- Do not lose data packets
- Cat5e solid copper keeps signal integrity intact
- Designed for active EMI reduction
- Minimal noise and crosstalk
10-YEAR WARRANTY, FREE DELIVERY
- Cat5e pure copper cable with plenum jacket is backed up by our 10-year warranty (Terms Apply)
Buy Cat5e Plenum Copper Cable 1000ft
The NewYork Cables solid copper cat5e cables is equipped with 100% solid bare copper conductors and a plenum jacket. The conductors are unshielded and twisted in pairs. Available in blue and white, the cat5e pure copper cable is ideal for both residential and commercial use.
Its plenum jacket makes sure it complies with fire safety standards.Moreover, the cat5e bare copper cable has undergone rigorous testing by NewYork Cables to ensure that it meets the highest quality standards so that you get the performance you need.
Unshielded Solid Copper Conductors
The cat5e 1000ft plenum cable features 4 pairs of 24 AWG conductors at its core. These wires are unshielded and wrapped inside an insulation. You can use either the EIA/TIA T568A or T568B wiring scheme to terminate.
The UTP cat5e solid cable is easier to install and the bare copper conductors make it ductile and easy to handle. Each conductor pair is twisted tightly to keep the electromagnetic interference and crosstalk at a minimum. The solid conductors also help keep interference at a minimum while ensuring high-quality data transmission.
Tested and Certified Cat5e Plenum Cable
As mentioned earlier, we have tested our solid copper cat5e cable and it is certified by all the industry regulatory bodies. The plenum jacket has undergone fire safety tests and it does not emit toxic smoke in case of a fire event.
It is also fire and heat-resistant which makes it safe for indoor air handling spaces such as HVAC units. The 1000ft cat5e cable is certified by the following industry standards: FCC, CE, CSA, ISO/IES, RoHS
Minimal EMI, Noise, and Crosstalk
Tightly twisted conductor pairs along with the solid copper conductors of the cat5e copper cable keep EMI, external Noise, and Crosstalk levels at a minimum. If you are buying the blue or white cat5e cable for a home or a commercial network, it will work flawlessly in both. Especially in commercial LAN networks where PoE is often used, this bare copper cable is ideal. Use it to connect IP cameras (CCTV), smart TVs, etc and it will relay signals without losing data packets.
Buy Cat5e Solid Copper - NewYork Cables
Place your order for Cat5e Plenum 1000ft solid bare copper cable now or get in touch with us. We will go above and beyond in swiftly shipping the best network copper cable on the market.
Our Cat5e 1000ft cable is available in multiple colors and you can also buy all the accessories you need along with it. Rest assured, the cable is backed up by our legendary 10-year warranty on pure copper Ethernet cables (Terms Apply).
