CAT5E Riser Solid Bare Copper Cable - UL Listed 24AWG UTP 4 Pair
UL-listed Cat5e riser cable designed with 24AWG solid bare copper conductors and four unshielded twisted pairs. It delivers up to 1Gbps data rates with 350MHz bandwidth. The CMR-rated jacket supports vertical installations by limiting flame spread. Twisted pair design helps control interference, supporting consistent signal performance in structured cabling systems.
In stock
- SKU
- NYC-V54x-UL-UTP
| Feature | Details |
|---|---|
| Cable Category | Cat5e |
| Category Type | Ethernet Cables |
| Speed | 1 Gbps |
| Frequency | 350 MHz |
| Conductor Diameter | 24 AWG |
| Jacket Rating | CMR (Riser) |
| Cable Length | 1000 feet |
| Conductor Material | 100% Pure Copper |
| Special Features | High-Speed, Noise Reduction, Low Latency, Easy Installation |
| For Use | Vertical Installations |
| Connector Type | RJ45 |
| Certifications | UL, FCC, ISO/IES, RoHS |
| PoE Compatibility | N/A |
| Twisted Pair Colors | Pair 1: Blue, White-Blue Pair 2: Orange, White-Orange Pair 3: Green, White-Green Pair 4: Brown, White-Brown |
| Shielding | UTP (Unshielded Twister Pairs) |
UL Listed CAT5E Riser 24AWG UTP 4 Pair Solid Bare Copper 350MHz 1000ft Pull Box
The Cat5e Riser cable has a CMR-rated outer jacket and it runs 24AWG. The Cat5e Riser Solid UL-Listed cable has been specifically designed for installation in the riser or vertical spaces of the buildings. The jacket of this cable is made from fine quality polyvinyl chloride that gives it fire-retardant properties; it means when the cable comes in contact with the blaze, it halts fire progression. As far as the bandwidth capacity of this cable is concerned, it stands at 350 MHz.
The cable has eight conductors that are made from pure copper and are tightly bundled together. Due to the presence of pure copper conductors, the Cat5e Riser UTP UL-Listed cable performs exceptionally well in harsh environments. It means the cable has excellent protection against all types of crosstalk and electromagnetic interference.
Cat5e Riser Solid UL-Listed cable has the following marking on its jacket: ETL VERIFIED CAT5E TO ANSI/TIA 568-C.2 ETL CMR 24 AWG 4PR 75C UTP c(ETL)us FT 4 350MHZ RoHS. Cat5e Riser UTP UL-Listed cable has data transfer rates of 1Gbps and 100Mbps over a distance of 50 meters and 100 meters respectively.
Being a UL-Listed cable means it has been widely tested against all the industry standards and is completely safe for use. Cat5e Riser Solid UL-Listed cable supports the following applications: ANSI X3T9.5 TP-PMD (FDDI), ATM PMD 155 Mbps IEEE 802.3 Fast Ethernet:10 Base-T, 100 Base-T4, 100 Base-X IEEE 802.5:4/16 Mbps Token Ring, IEEE 802.12:100 Base-VG.
It meets all industry standards and is RoHS compliant. It has also passed fluke testing. To get the best Cat5e Riser UTP UL-Listed Cable, you can always rely on NewYork Cables.
