CAT5E Plenum 24AWG UTP 4 Pair Solid Bare Copper 350MHz TAA UL Listed

10
( 10 Reviews )
SKU: NYC-V512

Available on backorder

Secure Payment
Free Quote
×

Get A Free Quotation






















SKU: NYC-V512 Category:

Features

  • 4 Pair, Unshielded 24 AWG
  • 100% Solid Bare Copper Conductors
  • Up To 100 MBit/s, 350 MHz
  • UL-Listed, ETL Verified, TIA/EIA568-C.2 Compliant
  • Communications Multipurpose Plenum (CMP)
  • Certified: FCC, CE, CSA, ISO/IES, RoHS

  • Secure Payment

  • Quick
    Refund

  • Original
    Product

  • 9AM to 5PM Support

  • Free Delivery Above $299

  • Quickest Delivery

UL Listed CAT5E Plenum 24AWG UTP 4 Pair Solid Bare Copper 350MHz 1000ft Pull Box White MADE IN USA

This Cat5e Plenum bears UL-Listed marking which means the cable has been extensively tested against all widely accepted industry standards and is completely safe for installation in the plenum spaces of the buildings. Being a plenum cable, the UL-Listed Cat5e Plenum cable comes with a CMP-rated jacket which means supreme quality material has been used in its making. This material gives the cable fire-retardant properties.

This Cat5 Plenum Solid UL-Listed cable comes with a bandwidth capacity of 350 MHz and supports data transfer rates of 1Gbps up to a distance of 50 meters and 100Mbps up to a distance of 100 meters. The thick jacket provides top-rated protection against all types of crosstalk and prevents electromagnetic interference. It means signal quality remains intact. The bare copper conductors surpass every aspect of the performance when compared to the copper-clad aluminum conductors. Therefore, if you are going to install cable in harsh environments, it is always better to use an ethernet cable that comes with bare copper conductors.

The inner structure comprises 8 pure copper conductors that are tightly bundled together in 4 twisted pairs. Cat5 Plenum Solid UL-Listed cable runs 24AWG. The biggest advantage of pure copper cable is that it has less attenuation thus keeping signal integrity intact. Also, pure copper conductors work extremely well in harsh environments. UL-Listed Cat5e Plenum cable supports the following applications: ANSI X3T9.5 TP-PMD (FDDI), ATM PMD 155 Mbps IEEE 802.3 Fast Ethernet:10 Base-T, 100 Base-T4, 100 Base-X IEEE 802.5:4/16 Mbps Token Ring, IEEE 802.12:100 Base-VG.

It meets all industry standards and is RoHS compliant. It has also passed fluke testing. To get the best UL-Listed Cat5e Plenum cable, you can always rely on NewYork Cables. We offer free shipping on orders worth $299.99.

Additional information

Color:

White
Number:

8 (4 Pair)
NVP:

72%
Conductor:

Solid Bare Copper
Conductor Size:

24 AWG
Diameter:

(.0198”/ .503 mm nom.)
Insulation:

FEP
Thickness:

0.0075” (0.190 mm)
Jacket:

FR-PVC
Overall Cable Diameter:

0.185’’ Nom. (4.70 mm)
Rip Cord:

Yes
Jacket Print:

c(UL)us CMP UTP FT6 75°C 24 AWG 4PR
VERIFIED (UL) CAT5e ANSI/TIA 568-C.2 ISO-IEC 11801 TESTED TO
350 MHz ROHS COMPLIANT MADE IN USA
Compliance:

c(ETL)us, TIA/EIA568-C.2
Safety Listing Standard:

UL 444
Operating Temperature:

-20°C To +75°C
Operating Voltage Rating (V RMS):

300
DC Resistance per Conductor @20°C (Ω/100m):

9.38
Mutual Capacitance (nF/100m Max):

5.6
Resistance Unbalance Max (%):

5
Capacitance Unbalance Max (pF/100m):

330
Nominal Impedance (±15%)(Ω):

100
Max Recommended Pull Tension (lb):

25
Min Bend Radius (in):

0.75
Applications:

ANSI X3T9.5 TP-PMD (FDDI), ATM PMD 155 Mbps IEEE 802.3 Fast
Ethernet :10 Base-T, 100 Base-T4, 100 Base-X IEEE 802.5 :4/16 Mbps Token
Ring, IEEE 802.12 :100 Base-VG
